Technical Data
| Machine Data | Dimensions | ||||
|---|---|---|---|---|---|
| Unwinding Reel Diameter | up to Ø800 mm | ||||
| Rewinding Reel Diameter | up to Ø800 mm | ||||
| Weight of the Reel | max. 150 kg(for both side) | ||||
| Max. Working Width | 500 mm | ||||
| Cyclinder Width | 550 mm. | ||||
| Unwinding Reel Inside Diameter | Ø76 mm (3") | ||||
| Rewinding Reel Inside Diameter | Ø 76 mm (3") | ||||
| Tension Range | Min.20 N- Max.200 N | ||||
| Mechanical working speed up to | 400 m/min; the speed value varies depending on the material and working conditions. | ||||
| Material Types Suitable For Use |
Paper 20 – 250 g/m2 B.O.P.P. 12 – 180 µ P.V.C. 20 – 180 µ L.D.P.E.(HDPE) 12 – 180 µ P.P. 12 – 180 µ PE 12 – 180 µ Aluminium Foil 12 – 100 µ Laminated Materials Up to 180 µ |
||||
| Unwinder and Rewinder Motors | 7,5 kW AC motors with encoder | ||||
| Color | Light Grey(RAL 7035) | ||||
| M/C direction | Suitable for both side |
