Technical Data

Machine Data Dimensions
Unwinder         Shafted Unit With Electromagnetic Powder Brake
Core Diameter Ø76 Air Shaft(Optional Ø152 Adaptor)
Tension Control Loadcell With Full Automatic Control
Width          1000/1300/1600
Speed         500 m/dk
Tension Renge 4 40 kg
Web Alignment      Ultrasonic / Contrast Color
Slitting Systems Circular Knives / Razor Knives
Rewinder           Turret System Wiyh Frictional Center Drive Technology, Four Motors
Core Diameter           Ø76 / Ø152 (OPTIONAL)
Rewinding Tension    Fully Automatic Control Via Plc With Digital Input
Analysis System           Recipe And Diagnostic Diagram
Core Alignment          With Laser Pointer
Reel Unloading         Manually With Reel Tree
Antistatic System         Antistatic Bar
